Indicators of Attack Installation Script

Run the IoA installation Script

To run the IoA script:

  1. Open PowerShell as Administrator, navigate to the script directory, adjust execution policy, and run the script:

    Copy
    .\Register-TenableIOA.ps1

  2. Enter the parameters relevant to your configuration:

    Parameter Description
    GPODisplayName The display name of the GPO used to create the task that registers the event listener. Default: Tenable.ad.
    TemporaryFolderLocation The temporary folder used to store the GPO backup during deployment. Default: %TEMP%\Tenable.ad\.
    DomainControllerAddress The FQDN or IP address of the domain controller to deploy to. Specify this if the script is run from a server or workstation that is not a domain controller. If omitted, domain information is retrieved from the local machine.
    DomainControllerOU The distinguished name of the Organizational Unit containing your domain controllers. Specify this if your DCs have been moved out of the default OU. Example: OU=Domain Controllers,DC=ROOT,DC=DOMAIN.
    TenableServiceAccount The name of the service account used by Tenable Identity Exposure, which requires explicit permission to read Group Policy Objects.
    Uninstall Uninstalls the event listener and WMI Active Script Consumer to stop event log collection. Default: false.
    ConfigurationFileLocation The path to the file that will be used to update the GPO configuration.
    Target

    A comma-separated list of domain controllers targeted by this registration script. Example: DC-ROOT1,DC-ROOT2. This parameter is optional.

    Tip: If used, ensure the list includes the PDCE; otherwise, the IoA deployment will fail.
    CleaningGPODisplayName The display name of the GPO used to create the cleanup task that removes the event listener and WMI Active Script Consumer. Default: Tenable.ad cleaning.
    EventLogsFileWriteFrequency The frequency (in seconds) at which the event log file is generated in DFSR mode for non-PDCE domain controllers. Default: 15 seconds. Maximum: 300 seconds (5 minutes). Optional parameter.
    SmbShareLocation The disk path (absolute) of the SMB share location when running on the PDCE in ‘Dedicated SMB share’ mode. This folder is managed by Tenable Identity Exposure. Default: C:\Tenable\IdentityExposure\IOALogs. Optional parameter.
    UseXmlEventRender Enables legacy XML-based event rendering for listeners. This method is slower but more stable than the values-based renderer. Disabled by default.

Group Policy Object

After you download and run the Indicators of Attack (IoA) installation file, the IoA script creates a new Group Policy Object (GPO) named by default Tenable.ad in the Active Directory (AD) database. The system links the Tenable Identity Exposure GPO only to the Domain Controllers' Organizational Unit (OU) that contains all domain controllers (DCs). The new policy automatically replicates between all DCs using the GPO mechanism.

The GPO contains PowerShell scripts that all DCs execute locally to collect data of interest, as follows:

  • The script configures an event logs listener on each domain controller using Windows EvtSubscribe API. The script makes a subscription for each necessary event log channel, as specified in the TenableADEventsListenerConfiguration.json configuration file, by submitting a request and a callback triggered by EvtSubscribe for each matching event log.

  • The event listener receives event logs and buffers them before periodically flushing them to a file stored in a network share called SYSVOL. Each DC flushes to a single SYSVOL file that stores collected events and replicates it to other domain controllers.

  • The script also creates a WMI consumer to ensure that this mechanism is persistent by re-registering the event subscriber when a DC restarts. WMI notifies the consumer each time a DC restarts to allow the consumer to register the event listener again.

  • At this point, Distributed File System (DFS) replication occurs and automatically synchronizes files between domain controllers. Tenable Identity Exposure's platform listens for incoming DFS replication traffic and uses this data to gather events, run a security analysis, and then generate IoA alerts.

Local Data Retrieval

Windows event logs record all the events that occur in the operating system and its applications. Event logs rely on a framework of components integrated in Windows.

Using the EvtSubscribe API, the Tenable Identity Exposure IoA events log listener collects only useful event logs data segments in the form of insertion strings that it extracts from the event logs. Tenable Identity Exposure writes these insertion strings in a file stored in the SYSVOL folder and replicates them via the DFS engine. This allows Tenable Identity Exposure to gather just the right amount of security data from event logs to run a security analysis and detect attacks.

IoA Script Summary

The following table gives an overview of the Tenable Identity Exposure script deployment.

Steps Description Component Involved Technical Action
1 Register Tenable Identity Exposure's IoA deployment GPO Management Creates the Tenable.ad (default name) GPO and links it to the Domain Controllers OU.
2 Start Tenable Identity Exposure's IoA deployment on DC DC local system Each DC detects the new GPO to apply, depending on the AD replication and Group Policy refresh intervals.
3 Control Advanced Logging Policy state DC local system The system activates the advanced logging policy by setting the registry key HKEY_LOCAL_MACHINE\System\CurrentControlSet\Control\Lsa\SCENoApplyLegacyAuditPolicy.
4 Update Local Logging policy DC local system Depending on the IoAs to detect, Tenable Identity Exposure dynamically generates and activates specific audit policies. This policy does not deactivate any existing logging policy — it only enriches them if necessary. If it detects a conflict, the GPO installation script stops and shows the message "Tenable Identity Exposure requires the audit policy '...' but the current AD configuration prevents its usage."
5 Register an event listener and a WMI producer DC local system The system registers and executes the script contained in the GPO. This script runs a PowerShell process to subscribe to event logs using EvtSubscribe API and to create an instance of ActiveScriptEventConsumer for persistence purposes. Tenable Identity Exposure uses these objects to receive and store event logs contents.
6 Collect event logs messages DC local system

Tenable Identity Exposure captures relevant event log messages, buffers them periodically, and saves them to files (one per DC) stored in the SYSVOL folder associated to the Tenable Identity Exposure GPO (...{GPO_GUID}\Machine\IOA<DC_name>).
7 Replicate files to the declared DC SYSVOL folder Active Directory Using DFS, the AD replicates files across the domain, and specifically in the declared DC. The Tenable Identity Exposure platform gets notification for each file and reads their content.
8 Overwrite these files Active Directory Each DC automatically and continuously writes the periodically buffered events in the same file.
